Clean Power You’ve seen those huge, white, and twirling wind turbines on the horizon before, but have you ever wondered how they actually work? Let’s break it down!

Published on June 30th, 2013 | by Dan Thiede, CERTs

41

What Is Wind Energy? Wind Energy 101

Share on Google+Share on RedditShare on StumbleUponTweet about this on TwitterShare on LinkedInShare on FacebookPin on PinterestDigg thisShare on TumblrBuffer this pageEmail this to someone

June 30th, 2013 by

You’ve seen those huge, white, and twirling wind turbines on the horizon before, but have you ever wondered how they actually work? Let’s break it down!

Wind turbines

What is wind energy?

Wind energy is electricity created from a wind turbine. (Side note: a common mistake is to call them windmills; however, the proper name is wind turbine. Windmills do spin and resemble wind turbines, but windmills actually pump water from the ground—think Dutch windmills.)

How do they actually work?

When the wind blows, it turns the blades of the turbine. As these blades turn, they spin generators to create electricity. The electricity is then sent to a transformer which increases the voltage and sends it to a distribution line. Next, local transformers reduce the voltage and send it to homes or businesses.

Why are they so tall?

Wind turbines are tall due to the fact that wind increases at higher altitude. The greater the wind resource, the more the turbine spins, and the more energy is produced for our use!

Why are some bigger than others?

In general, the larger the wind turbine, the more electricity the turbine generates. From Windustry: “Wind turbines range in size from tiny micro turbines to enormous utility-scale power production facilities. Large turbines may have blades that are over 50 meters long—meaning the rotor diameter would be over 100 meters long—more than the length of a football field! The commercial-scale turbines are often placed on 100 meter towers, so the tip of the blades might reach as high as 160 meters (525 feet) in the air. Smaller home- or farm-sized turbines usually have a rotor diameter of up to 15 meters (50 feet) and can be placed on 30 to nearly 50 meter towers.”

Is there enough wind near you for a wind turbine?

There is a huge potential for wind energy across the entire United States. Not only do most of our states have high enough average wind speeds to make wind turbines effective, but the wind energy business in general is booming. You can see approximate wind resource potential near you by checking out maps from DOE’s Wind Powering America Program.

Are they loud?

A rule of thumb to keep in mind is that the closer you are, the louder the wind turbines are. When standing directly below a wind turbine, the noise level is slightly above that of a vacuum cleaner. 100 meters away, the level drops to roughly the level of a microwave oven. 300 meters away, the noise level is equal to that of a kitchen refrigerator. By standard protocol, wind turbines are never closer than 300 meters from the nearest residential structure.

How are they being used right now?

See the original story on the Clean Energy Resource Teams’ website.

Keep up to date with all the hottest cleantech news by subscribing to our (free) cleantech newsletter, or keep an eye on sector-specific news by getting our (also free) solar energy newsletter, electric vehicle newsletter, or wind energy newsletter.



Share on Google+Share on RedditShare on StumbleUponTweet about this on TwitterShare on LinkedInShare on FacebookPin on PinterestDigg thisShare on TumblrBuffer this pageEmail this to someone

Tags: , , , , , , , ,


About the Author

is the Communications Coordinator for the Clean Energy Resource Teams, or CERTs, at the University of Minnesota. CERTs works to advance the adoption of renewable energy and energy efficiency projects in communities across Minnesota by helping people learn, connect, and act.
